120Res-DDC Body
Compact Reservoir for DDC Pump
The Glacier EZ-Fit 120RES-DDC reservoir is designed for compact versatility, featuring a flexible mounting system that enables easy installation onto any fan in various orientations. With its exact 120 by 120 mm size, it fits exactly into any 120 mm fan position or onto any 120 mm or 140 mm fan in the system.
Colors
Specifications
General
Model No.
PH-GEF_RES120-B_DBK01
UPC Code
886523703303
Product Type
Reservoir
Color
Black
Form Factor
Compact reservoir combo for DDC
Materials
Cast acrylic | Aluminum cover | Brass fitting | ABS fitting inserts | EPDM-NBR O-rings
Technical Details
Dimensions
Width x Height x Depth
120 x 124 x 45 mm | 4.72 x 4.88 x 1.77 in
Pump Compatibility
DDC
Not included
Liquid Capacity
120 ml
Inlet Ports
2x M24
Outlet Ports
2x M24
Fill Port
1x G¼ brass stop fitting Pre-installed
Plugs
2x M24 acrylic plug fitting Pre-installed
Fittings
2x M24 EZ-Fit 16 mm fittings Pre-installed
Hard Tube Support
16 ± 0.1 mm OD | HI-PMMA | PMMA | Acrylic | PETG | Glass
Soft Tube Support
16 ± 0.1 mm OD | H10 ± 0.1 mm ID | PVC
Mounting Support
120-140 mm Fan | Radiator | 120 mm Chassis fan location
LED Number
10
LED Max. Rated Current
0.3A
Extra
Scope of Delivery
1x 120RES reservoir
Accessory Box
3x Fitting inserts
1x Fan mounting bracket
1x D-RGB mainboard adapter 500 mm
1x D-RGB LED cable
1x 2.5 mm Hex key
1x 8 mm Hex key
Screws
2x M4x8 mm Bracket screws
2x M4x10 mm Mounting screws
4x M4x25 mm Pump screws
4x Fan screws
