Evolv X2

Redefine the desktop computer

The Evolv X2 redefines the desktop computer with its see-through glass design, aluminum interior, and powerful vertical cooling solution. The entire chassis floats above its base, drawing in surrounding air and channeling it efficiently through the GPU and CPU. Hot air is expelled through the top ventilation, enhancing thermal performance.

The interior of the Evolv X2 has been carefully designed to blend with the hardware components for a fully integrated look, with all cooling components sitting flush into the top and base. The integrated lighting and high-quality aluminum internal panels add flair to your system.

Colors

Brushed Black

Silver White

Designed To Cool

  • Efficient vertical airflow design, drawing fresh air from the bottom and expelling warm air through the top.

  • Floating chassis design ensures superior cooling by maximizing air intake through the bottom fan positions.

  • Hot air is exhausted through the top, directed away from the user, thanks to the slanted grill design.

Looking Clean

  • Mainboard and graphics card sitting front and center.
  • Cooling fans and radiator sit hidden into the chassis as one.
  • The large cover door fully hides all cables behind the mainboard.
  • Supports rear-connect mainboards for a zero-cable build.

Premium Build Quality

  • Super strong steel and aluminum C-frame design.
  • Unique see-through chassis showcases the mainboard and graphics card.
  • Brushed aluminum interior wrapped around the cooling components.

Integrated Lighting

  • Smooth and diffuse D-RGB lines run from top to bottom of the Evolv X2.
  • 3x built-in D-RGB LED strips are pre-installed and connected.

To operate the D-RGB lighting, it must be connected to a Phanteks controller or an A-RGB equipped mainboard. We strive to make it as easy to use and compatible as possible.

Storage

  • Side Storage Bracket
    Supports 3x 2.5″ SSD drives.

  • Bottom Storage Bracket
    Supports 2x 3.5” HDD drives or 1x 3.5” HDD and 2x 2.5” SSD drives.

Fan Positions

  • Top
    3x 120 mm
  • Rear
    1x 120 mm
  • Bottom
    3x 120 mm

Radiator Positions

  • Top
    1x 360 Up to 410 x 130 x 38 mm

Evolv X2 | Black Gold is a limited edition in collaboration with and is exclusively sold by Caseking and Overclockers UK. To find out more, please visit Caseking or Overclockers UK.

Specifications

General

Model No.

PH-ES524XTG_DBK01

UPC Code

886523303688

Case Dimensions

454 x 228 x 588 mm | 17.87 x 8.98 x 23.15 in

From Factor

Mid-Tower

Mainboard Support

*E-ATX | ATX | Micro-ATX | Mini-ITX

*Up to 280 mm wide

Materials

Steel chassis | Aluminum panels | Tempered glass window | ABS plastic

Color

Brushed black aluminium

Expansion Slots

8

Vertical GPU Support

Yes

Riser cable & bracket sold separately

Internal 2.5″ Positions

5

+ 1x 3.5″ HDD

Internal 3.5″ Positions

2

+ 3x 2.5″ SSD

Front I/O

2x USB 3.0
1x USB-C 3.2 Gen2x2
1x Microphone | Headphone combo
Power button
Reset button

Fans 120 | 140

Total Fans

7 |

Top

3 |

Front

|

Side

|

Rear

1 |

Bottom

3 |

Radiator 120 | 140

Top

Max. 360 |

Front

|

Rear

|

Bottom

|

Clearance

CPU Cooler

Height

170 mm | 6.69 in

GPU

Length

380 mm | 14.96 in

GPU

Width

170 mm | 6.69 in

Power Supply

250 mm | 9.84 in

Top 360 Radiator

Length x Width x Height

415 x 130 x 32 mm | 16.34 x 5.12 x 1.25 in

Extra

Net Weight

14.2 kg | 31.3 lbs

Gross Weight

16.5 kg | 36.4 lbs

Warranty

5 Years Limited

Scope of Delivery

1x Evolv X2 chassis
1x Storage bracket Pre-installed
1x SSD bracket Pre-installed

Accessory Box

6x Zip ties
1x Stand-off removal tool
1x D-RGB mainboard adapter 500 mm
1x Microfiber cloth

Screws

30x Mainboard | SSD screws
4x Power supply screws
8x HDD screws
4x Vertical-GPU bracket screws
1x Mainboard stand-off

Support

Documentation

FAQ

What is Digital-RGB?

Digital-RGB means that each LED chip can be controlled individually, allowing for multiple colors and effects in a single D-RGB LED strip. While regular RGB LED strips can only show the same color on each LED chip per strip at a time. However, not every Digital-RGB (Addressable) product is the same.

Phanteks D-RGB products

Are plug-and-play. No software is needed, yet it is compatible with software control through MSI or ASUS compatible motherboards if desired. Have custom developed color patterns. We believe D-RGB lighting can be stylish when having the right color/pattern settings, which is why the Phanteks D-RGB controller is pre-installed with custom selected color modes and patterns.

Have 30 LED chips. This is a lot! Having 30 LEDs per product instead of just 8 or 12 creates a much more beautiful color gradient and higher quality lighting. This also means more color tints can be displayed simultaneously in one strip.

Why are Digital-RGB and RGB not compatible?

Digital-RGB and RGB have a different connector. Digital-RGB uses a 3-pin connector while RGB uses a 4-pin connector. Technical explanation: Digital-RGB uses 5 Volts while RGB uses 12 Volts. Connecting Digital-RGB products and RGB products would cause damage.

Is Digital-RGB compatible with my mainboard?

Digital-RGB from Phanteks is compatible with Asus Addressable-equipped motherboards and MSI Mystic Light Rainbow-equipped motherboards. Check with the Motherboard specifications if your motherboard has a ‘AURA Addressable Header’ or a ‘Mystic Light Sync Rainbow header’ with 3 pins.

How many D-RGB products can I connect to a compatible mainboard?

Each D-RGB product uses 1 Ampere. Check the power output with your motherboards specifications to determine how many D-RGB products can be powered by your mainboards. Currently mainboards support 3 Amperes.

How many D-RGB products can I connect to the D-RGB controller from Phanteks?

The Phanteks D-RGB controller can support up to 7 D-RGB products when using the remote. If the D-RGB controller is connected to your motherboard a total of 9 D-RGB can be connected to the controller. A maximum of 4 D-RGB products can be connected to a single output port on the controller.

How do I connect my D-RGB product from Phanteks to my mainboard?

Most of the D-RGB products and compatible mainboards include a mainboard adapter. Simply connect this mainboard adapter to the Addressable or Rainbow port on your mainboard and the Phanteks D-RGB products. D-RGB products from Phanteks can be daisy-chained so you only need one port on your motherboard. Most mainboards also include this motherboard adapter cable.

Can I install multiple Digital-RGB controllers in my case?

You can install as many D-RGB controllers as you would like. However they do not connect to each other. Each controller will work, and need to be controlled, individually.

How do I turn off the D-RGB LED’s on the Phanteks D-RGB controller?

Press and hold the ‘Mode’ for 2 seconds until the LED’s turn off. When using software control please consult with the motherboard manufacturer.

Can’t find the answer you’re looking for?
Contact us through the SUPPORT button in the bottom right corner of the website.
